COMPARELaunch EM101N EV Oscilloscope & Multimeter
- Model : EM101N
- Country of Origin : China
The Launch EM101N EV Oscilloscope & Multimeter is an advanced diagnostic device designed for electric vehicles and new energy vehicles. It combines the functions of a digital multimeter and a dual-channel oscilloscope in one compact solution, providing technicians with versatile measurement and waveform analysis capabilities.
The EM101N helps technicians diagnose electrical and electronic systems by displaying waveform diagrams and measurement data, improving diagnostic efficiency and reducing troubleshooting time.
The device features a protective anti-fall rubber sleeve and a convenient plug-in fuse design for easy replacement. It can also connect to Launch X-431 diagnostic tools through either wired or wireless communication and features a new user interface with three selectable display modes.
2-in-1 Diagnostic Device
Combines Multimeter and Dual-Channel Oscilloscope functions in one device for comprehensive electrical testing.
Dual-Channel Oscilloscope
Equipped with two analog channels for displaying and analyzing electrical signals and comparing waveforms during diagnostics.
10MHz Bandwidth
Provides a bandwidth of up to 10MHz for analyzing a wide range of electrical and electronic signals.
Up to 50MHz/s Real-Time Sampling Rate
Provides a maximum real-time sampling rate of 50MHz/s for detailed waveform analysis.
Launch X-431 Compatibility
Supports wired and wireless connection with Launch X-431 diagnostic tools, providing flexible diagnostic operation.
New User Interface
Features a new UI design with three selectable display modes for convenient data visualization.
User-Friendly Diagnostic APP
The new diagnostic application provides an intuitive interface and supports local waveform saving and waveform opening.
Anti-Fall Protection
The protective rubber sleeve helps protect the device against accidental drops and impacts during workshop use.
Convenient Fuse Replacement
Features a unique plug-in fuse design for quick and convenient fuse replacement.
Comprehensive Test Accessories
Supports a range of testing accessories including needle sets, multimeter test leads, alligator clips, and oscilloscope channel test leads.
Designed for EV Diagnostics
Suitable for testing and diagnosing electrical and electronic systems in electric vehicles and new energy vehicles.
| Name | - |
|---|---|
| Current Range | DC: ±10A / AC: ±10A |
| Channels | Two analog channels |
| Connectivity | Wired / Wireless with X-431 diagnostic tool |
| Operating Temp. | 0–50°C |
| Dimensions | 180 × 174 × 65.5 mm |
| Weight | 1.7kg |
| PROTECTION | Anti-fall rubber sleeve, fuse plug-in design |
| DC Voltage | Automatic range, ±600V |
| AC Voltage | Automatic range, ±600V |
| DC Current | Automatic range, ±10A |
| AC Current | Automatic range, ±10A, average value measurement |
| Resistance | Automatic range, 0–6MΩ |
| On and off | Buzzer when resistance is less than 30Ω |
| Diode | 0.5–2.0V |
| Battery Capacity | 3100mAh |
| Bandwidth | 10MHz |
| Real-time Sampling Rate (Max) | 50MHz/s |
| Time Base Range | 1μs/div–10s/div, step by 1–2–5 times |
| Sampling Mode | Normal sampling, peak detection, average |
