Brand: TEXA
TEXA FREON CHARGING MACHINE 710 TOUCH
Model: KONFORT 710 TOUCH
Country of Origin: Italy
The TEXA KONFORT 710 TOUCH is the entry-level model of TEXA’s smart TOUCH series, designed to bring advanced technology and intuitive operation into professional workshops.
It combines a modern touchscreen interface with high precision charging and recovery performance, making daily A/C service faster, safer, and more efficient.
Refrigerant Type & Supported Vehicles :
Refrigerants: R134a / R456a
Compatible with:
Passenger cars / SUVs & light commercial vehicles / Hybrid vehicles / Electric vehicles (EVs) .
Main Operating & Service Functions :
Fully automatic A/C service management via DATABASE
(Recovery – Vacuum – Leak detection – Recharging)Automatic leak detection before charging
Automatic refrigerant quantity calculation based on vehicle database
High charging accuracy up to ±15 g thanks to the electronic scale
Refrigerant recovery efficiency above 95%
Automatic compensation for service hose length to ensure precise charging
Despite its smart software, the machine is equipped with 2 manual service hose control valves for mechanical operation during the service process.
Oil & UV Dye Management :
Fully automatic oil and UV dye injection
Timed injection system to ensure compressor protection and service accuracy
Automatic management of non-condensable gases
User Interface & Operating System :
7-inch color touchscreen display
Android 10 operating system with an intuitive, smartphone-like interface
Glove-touch technology, allowing use while wearing work gloves
High brightness and clear visibility in workshop environments
Connectivity & Smart Features :
Built-in Wi-Fi, enabling:
Automatic software and database updates
Wireless printing of A/C service reports
Remote assistance from TEXA technical support
USB & Bluetooth connectivity for data backup and accessories
KONFORT APP compatibility for monitoring service status via smartphone
OFF ROAD Version (Heavy-Duty Use) :
Scale Locking System to protect scale calibration from vibrations
4 reinforced wheels for easy movement on uneven surfaces
Heavy-duty mechanical structure for harsh workshop conditions
Storage and management of service reports
Optional Accessories :
Thermal printer for service reports
Flushing Kit for A/C system cleaning
A/C System Efficiency Kit
Forming Gas Leak Detection Kit .
| Name | - |
|---|---|
| Display | 7” TFT IPS 1024×600 400CD |
| GPU | Qualcomm© Adreno™ 308 Graphics Processing Unit (GPU) with 64-bit addressing |
| Touch | Capacitive touch panel, USB/12C interface |
| CPU | SC200R Series Snapdragon QCM2150 Quad-core ARM Cortex-A53 64-bit CPU @ 1.3 Ghz STM32F103 – ARM Cortex M3 32-bit CPU |
| RAM | 2 GB LPDDR3 |
| HAM:Hard disk | 16 GB eMMC |
| Operating system | Android 10.0 |
| Audio peripheral | devices 1 speaker CES-703116-28PM 8ohm 2W |
| Wi-Fi | 802.11a/b/g/n, 150 Mbps, STA/AP/P2P 2402-2480 MHz 5 Ghz |
| Bluetooth | 2.1+EDR/3.0/4.1 LE/4.2 BLE 2400-2483,5 MHz |
| RF power | 20 dBm |
| I/O peripheral | devices USB 2.0 x1 |
| Fluid / Group | R134a / 2 R456a / 1 |
| Electronic refrigerant scale (Precision) [g] | ± 10 |
| Electronic oil and UV tracer scales (Resolution) [g] | - |
| High pressure gauge [mm] | Ø 80 |
| Low pressure gauge [mm] | Ø 80 |
| Tank capacity [kg] | 20kg |
| Vacuum pump | 100 l/m, double stage, final pressure 0,03 mbar |
| Recovery efficiency | > 95 % (SAE J2788 / SAE J2843) |
| Power supply voltage [V] | 230V |
| Frequency (Hz) | 50Hz |
| Power [W] | 770W |
| Operation temperature (TS) [°C] | 5 ÷ 40 |
| Storing temperature [°C] | – 25 ÷ 60 |
| Primary battery | 3 V CR2032 |
| Secondary battery | NiMh 2,4 V – 600 mAh |
| Pressure transducer | Kl. 1.0 |
| Service pipes’ length [m] | 3m |
| Filter assembly | 1 combined filter + mechanical filter |
| Compressor (airtight) [cc] | 12 |
| Ambient temperature sensor (Resolution) [°C] | 1° |
| Refrigerant purity [kg] | 150 (SAE J2099) |
| Maximum operating pressure (PS) [bar] | 20Bar |
| Safety device calibration [bar] | 20Bar |
| Dimensions [mm] | H: 1101 L: 598 P: 706 |
| Weight [kg] | 90kg |
